Manitowoc Published 08-12-19, Control # 224-13 3-27
MLC650 OPERATOR MANUAL OPERATING CONTROLS AND PROCEDURES
3
1
3
Operation of Diverting Circuits
Diverting Circuit 1
Condition Drum 1 Left Crawler Drum 6
1 Full Parked Parked
2 Parked Full Parked
3 Parked Parked Full
41/2FullParked
5 1/2 Parked Full
6 Parked Full Full
Diverting Circuit 2
Condition Drum 2 Right Crawler Drum 3
1 Full Parked Parked
2 Parked Full Parked
3 Parked Parked Full
41/2FullParked
5 1/2 Parked Full
6 Parked Full Full
NOTES
• For either diverting circuit, only two of the functions can be operated at a time
• Unused functions must be parked
• Full = indicated function can be operated up to full speed
• 1/2 = indicated function can be operated up to half speed
