OPERATING CONTROLS AND PROCEDURES MLC650 OPERATOR MANUAL
3-16
Published 08-12-19, Control # 224-13
Left Console
Table 3-5. Left Console
Item Name Description
1 12VDC Power Source
Maximum current draw is 10A. For fuse location, see Section 3 of the Service
Manual.
2 Seat Riser Control
Item Description
A Engage switch in this location to raise or lower the rear riser.
B
Engage switch in this location to raise and lower the seat and to
move the seat forward or backward.
C Engage switch in this location to raise or lower the front riser.
To Next Page
