SET-UP AND INSTALLATION MLC650 OPERATOR MANUAL
4-8
Published 08-12-19, Control # 224-13_v2
SWING LIMITS
Reference Table 4-2 and Table 4-3 for swing data during
crane assembly and disassembly.
Table 4-2 Crane Configurations on Pedestals
NOTE: Mast hoist (drum 4) operation is not permitted at
radii greater than 8,5 m (29 ft).
Refer to the Liftcrane Mast Capacities Chart at the end of this
section for detailed lifting capacities with the mast and self-
erect cylinder.
Crane Configuration Swing
Max
Capacity
Max
Radius
• Crane on pedestals (rotating bed, adapter frame, and carbody)
• Live mast in operating range (110°-158°)
• No crawlers
• No counterweight
30° Either Side of Center
See Figure 4-9
• Crane on pedestals (rotating bed, adapter frame, and carbody)
• Live mast in operating range (110°-158°)
• No crawlers installed (handling 1st crawler)
• No counterweight
30° Either Side of Center
See Figure 4-9
54 430 kg
120, 000 lb
8,5 m
(29 ft)
• Crane on pedestals (rotating bed, adapter frame, and carbody)
• Live mast in operating range (145°-158°)
• First crawler installed
• No counterweight
360°
• *Crane on pedestals (rotating bed, adapter frame, and carbody)
• Live mast in operating range (110°-158°)
• First crawler installed and resting on the ground
• No counterweight
*See note for this section
360°
54 430 kg
120, 000 lb
8,5 m
(29 ft)
• Crane on crawlers
• Counterweight installed (fully retracted) or removed
• Handling loads with live mast
360°
NOTE: *Pedestals installed only on the side of the carbody opposite the 1st crawler.
WARNING
Crane Tipping Hazard!
To avoid serious or fatal crushing injury, do not
exceed operating radii and capacities given in the
Liftcrane Mast Handling Capacities Chart. Structural
failure or crane tipping will occur.
FIGURE 4-9
Swing Limited to 30° (1) for Handling the First Crawler Over
Side of Crane on Carbody Pedestals
