SET-UP AND INSTALLATION MLC650 OPERATOR MANUAL
4-192
Published 08-12-19, Control # 224-13_v2
Moving Operator Cab (Shipping Position)
NOTE: Securing the cab in the setup position allows for
access to the cab and removal of the cab platforms
and handrails when the rotating bed jacking
cylinders are deployed.
See Figure 4-148
for the following procedure:
1. Remove the pin and safety pin (1) from the strut (2)
attached to the rotating bed (3) as shown in the working
position.
2. Rotate the cab to the setup position and insert the pin
and safety pin (1) through the strut (2) to secure the cab.
FIGURE 4-148
WORKING POSITION
SETUP POSITION
WORKING POSITION
Item Description
1 Pin and Hair-Pin Cotter
2Strut
3 Rotating Bed
4 Operator Cab Support
