Manitowoc Published 08-12-19, Control # 224-13_v2 4-191
MLC650 OPERATOR MANUAL SET-UP AND INSTALLATION
4
Item Description
1 Pin and Safety Pin
2 Platform Brace
3Hitch Pin
4 Platform Storage Brace
5a Pin Position
5b Hole
6 Locking Pin
7 Platform Storage Bracket
FIGURE 4-147
SHIPPING POSITION
