SET-UP AND INSTALLATION MLC650 OPERATOR MANUAL
4-60
Published 08-12-19, Control # 224-13_v2
Deploying Operator Cab (Working Position)
See Figure 4-49 for the following procedure:
1. Remove the locking pin and pins (1) from the strut that
secures the operator cab support (4) to the rotating bed
(3).
2. Rotate the operator cab to the working position.
3. Install the strut (2c) using the locking pin and pins to
secure the operator cab in the working position.
FIGURE 4-49
Item Description
1 Locking Pin and Pin (qty 3)
2b Strut (setup position)
2c Strut (working position)
3 Rotating Bed
4 Operator Cab Support
SETUP POSITION
WORKING POSITION
