Manitowoc Published 08-12-19, Control # 224-13 3-7
MLC650 OPERATOR MANUAL OPERATING CONTROLS AND PROCEDURES
SYMBOLS USED ON REMOTE CONTROL
The following symbols are used on the remote control to identify the operating controls and their operation.
Table 3-3. Symbol Identification — Remote Control
Alert
Battery
Counterweight Tray
Counterweight Tray (In/Out)
Cylinder, Mast Assist (Extend/
Retract)
Cylinder, Rotating Bed Jack
Storage, Front
Cylinder, Rotating Bed Jack
Storage, Rear
Data, Confirm
Data, Select
Energize
Engine
Horn
Jack (Extend/Retract)
Jack, Carbody (all)
