SET-UP AND INSTALLATION MLC650 OPERATOR MANUAL
4-190
Published 08-12-19, Control # 224-13_v2
Storing Rotating Bed Platforms
The rotating bed platforms are attached to the rotating bed
and must be flipped up or down to the stored position.
NOTE: Use the anchors (shown in Figure 4-2
) supplied to
attach the safety harnesses.
See Figure 4-146
for the following procedure:
1. In the working position, remove the pin and safety pin (1)
from the platform brace (2).
See Figure 4-147
to continue the procedure:
2. Insert the pin and safety pin (1) back into the platform
brace (2).
3. Swing the platform brace into the platform and secure
with the hitch pin (3).
4. Swing the platforms down (upper rear platforms swing
up), attach the platform storage brace (4) to the platform
storage bracket (7), and insert the pin and safety pin.
NOTE: The upper rear platforms have two positions for
shipping. The pin position (5a) is used for shipping
with a live mast, and the hole (5b) is used for
shipping without a live mast.
5. Repeat the procedure for each platform section.
WORKING POSITION
FIGURE 4-146
Item Description
1 Pin and Safety Pin
2 Platform Brace
To Next Page
