OPERATING CONTROLS AND PROCEDURES MLC650 OPERATOR MANUAL

3-80

Published 08-12-19, Control # 224-13

Item Description

1 APU (auxiliary power unit)

2 Locking Pin with Hair-Pin Cotter (2)

3 Hook (2)

4 Fixed Pin (2)

5 Adjusting Bolt with Nuts (2)

6 Air Conditioner Hose (2)

7* Fuel Hose (2)

8* Electric Cable (DC, WAC1)

9* Electric Cable (DC, WAD1)

10* Power Supply Cable (AC, WAA1)

11 Interlock Switch

12 Interlock Switch

13 Battery Disconnect Switch

14 Identification Plate

* Stored in Job Box

Figure 3-27. AC Generator
