SET-UP AND INSTALLATION MLC650 OPERATOR MANUAL
4-4
Published 08-12-19, Control # 224-13_v2
FIGURE 4-5
Item Description
1Live Mast
2 Live Mast Links/Straps
3 Self-Erect Cylinder
4 Cylinder Rod End
5 Shackle (qty 2)
6 Synthetic Lifting Sling (not shown)
7 Operator Cab
8 Crawler (qty 2)
9 Carbody Jacking Cylinders (qty 4)
10 Carbody
11 Outrigger Pads (4)
12 Rotating Bed Jacking Cylinders (qty 4)
13 Rotating Bed
14 Gantry
15 Boom Hoist Rope
16 Live Mast Hoist (Drum 4)
17 Mast-Assist Cylinders (qty 2)
