Manitowoc Published 08-12-19, Control # 224-13 1-3
MLC650 OPERATOR MANUAL INTRODUCTION
1
Item Description
30-35 Not Used
36 Batteries (rear of rotating bed)
37 DEF Exhaust System
38 Air Intake
39 Pump Drive and Hydraulic Pumps
40 Hydraulic Tank
41 Engine with Pump Drive Disconnect
42 Cooler (coolant, hydraulic oil, charge air)
Figure 1-3 continued
