SET-UP AND INSTALLATION MLC650 OPERATOR MANUAL
4-42
Published 08-12-19, Control # 224-13_v2
FIGURE 4-35
Item Description
1 Pin (stored position)
2 Pin (shipping position)
3Shim
4 Safety Pin
5 Alignment Pin
6 Pin Puller Cage
7 Operating Pin
8a Keeper Pin
8b Keeper Bar
9Drum Hoist Frame
10 Hitch Pin with Hair-Pin Cotter
11 Live Mast Strap
View A
View B
View C
View C
SHIPPING
WORKING
