FIGURE 4-57
Item Description
1 Lock Nut and Bolt (qty 8)
2 Drive Shaft Flange
3 Locking Pin
4Latch
5 Crawler Drive Shaft
6 Storage Bracket
7 Companion Flange
8Collar
9 Locking Pin (qty 2)
10 Drive Shaft Guard (qty 2)
11 Drive Shaft Lever
COLLAR NOT ENGAGED
COLLAR ENGAGED
SHIPPING POSITION
WORKING POSITION
View A
View B
