SET-UP AND INSTALLATION MLC650 OPERATOR MANUAL
4-80
Published 08-12-19, Control # 224-13_v2
FIGURE 4-64
Item Description
1a Counterweight Tray Hydraulic Hoses (stored position)
1b Counterweight Tray Hydraulic Hoses (working position)
2a Connecting Link (stored position)
2b Connecting Link (working position)
3 Rotating Bed Electrical Cable (WVB-1) connects to (WVT1-P1)
4 Rotating Bed Electrical Cable (WVB-2) connects to (WVT2-P1)
