SET-UP AND INSTALLATION MLC650 OPERATOR MANUAL
4-82
Published 08-12-19, Control # 224-13_v2
.
FIGURE 4-66
Item Description
1 Counterweight Tray
2 Rotating Bed
3 Physical Stop on Tray (1 each side)
4 Physical Stop on Bed (1 each side)
