SET-UP AND INSTALLATION MLC650 OPERATOR MANUAL
4-92
Published 08-12-19, Control # 224-13_v2
Item Description
1 12M Insert W/Sheaves
2 Ladders
3 Ladder Mounting Bracket without Latch
4 Ladder Mounting Bracket with Latch
5 Rubber Latch
6 Lower Pad
WORKING POSITION
STORED POSITION
FIGURE 4-72
