SET-UP AND INSTALLATION MLC650 OPERATOR MANUAL
4-106
Published 08-12-19, Control # 224-13_v2
FIGURE 4-82
Item Description
1Boom Top
2 Connecting Pin with Safety Pin (2-4)
3 Lower Boom Point (4 sheave right side)
4 Lower Boom Point (8 sheave center)
5 Lower Boom Point (4 sheave left side)
6 Long Pin (5)
7 Short Pin (5)
8 Links (14)
9 Lifting Lug (2)
10 Lifting Link (2)
View A
Boom Only
View B
Boom Only
View C
Boom Only or Boom
with Luffing Jib
View D
Boom with Luffing Jib
View D
SHIPPING
View E
WORKING
