SET-UP AND INSTALLATION MLC650 OPERATOR MANUAL
4-154
Published 08-12-19, Control # 224-13_v2
Item Description
1 Lifting Plates
2 Lifting Pendant (qty 4)
3 Counterweight Tray
4 Tag Line
5 Rotating Bed
6 Front Vertical Rollers
7 Front Horizontal Rollers
8 Large Stop Block (qty 2)
9 Small Stop Block (qty 2)
10 Rotating Bed
Counterweight Tray Rack
FIGURE 4-121
