SET-UP AND INSTALLATION MLC650 OPERATOR MANUAL
4-156
Published 08-12-19, Control # 224-13_v2
FIGURE 4-122
SHIPPING POSITION
WORKING POSITION
(4)
Item Description
1 Locking Pin (qty 2)
2 Safety Pin (qty 2)
3 Hitch Pin (qty 2)
4 Strut (qty 2)
5 Platform Bracket
6 Carbody Platform Bracket
7 Hitch Pin (qty 2)
8 Adjuster
