SET-UP AND INSTALLATION MLC650 OPERATOR MANUAL
4-160
Published 08-12-19, Control # 224-13_v2
FIGURE 4-125
View D
View B
View A
STORED POSITION
Item Description
1 Rotating Bed
2Crawler
3 Carbody Jacking Cylinder (qty 4)
4 Outrigger Pad (qty 4)
5 Strut (qty 4)
6 Safety Pin and Pin (qty 2)
7 Jack Lug
8 Carbody Lug
9 Locking Pin
View C
WORKING POSITION
