SET-UP AND INSTALLATION MLC650 OPERATOR MANUAL
4-166
Published 08-12-19, Control # 224-13_v2
FIGURE 4-129
Item Description
1 Rotating Bed
2 Sling (qty 3)
3 Crawler (qty 2)
4 Carbody Jacking Cylinder (qty 4)
5 Carbody Distance
