SET-UP AND INSTALLATION MLC650 OPERATOR MANUAL
4-182
Published 08-12-19, Control # 224-13_v2
Item Description
1 Drum 4 Pawl Hydraulic Connector (qty 2)
2a Drum 4 Hydraulic Hose (stored position) (qty 4)
2b Drum 4 Hydraulic Hose (working position) (qty 4)
3 Drum 4 Electrical Connector
4a Live Mast Hydraulic Hose (stored position) (qty 2)
4b Live Mast Hydraulic Hose (working position) (qty 2)
5 Live Mast Electrical Connector (WRM-P1)
6 Live Mast Grounding Wire
FIGURE 4-140
