SET-UP AND INSTALLATION MLC650 OPERATOR MANUAL
4-198
Published 08-12-19, Control # 224-13_v2
FIGURE 4-154
Item Description
1 Rotating Bed Jacking Cylinder (qty 4)
2 U-Shaped Locking Pin
3 Outrigger Pad
4 Rotating Bed
5 Rotating Bed Lug
6 Outrigger Strut (qty 4)
7 Outrigger Beam Assembly
8 Jacking Cylinder Pin
9 Locking Pin
10 Outrigger Pad Locking Pin
11 Beam
VIEW A
VIEW B
