MLC650 OPERATOR MANUAL OPERATING CONTROLS AND PROCEDURES
3
1
3
Jack, Rotating Bed
Left Rear and Left Front
Jack, Rotating Bed
Left Front
Jack, Rotating Bed
Left Front and Right Front
Mast, Live
Off
On
Pin (Disengage)
Pin (Engage)
M102764
M102765
M102766
M102435
M100170
M100171
M100177
M100178
Pin, Adapter Frame to Rotating Bed,
Front
Pin, Adapter Frame to Rotating Bed,
Rear
Pins, Crawler Left
Pins, Crawler Right
Pins, VPC-MAX Beam
Signal, Transmission
Speed, Fast
Speed, Slow
M102756
M102757
M102437
M102436
M102758
M102441
M100183
M100184
