Manitowoc MLC650 User Manual

Manitowoc Published 08-12-19, Control # 224-13 3-13
MLC650 OPERATOR MANUAL OPERATING CONTROLS AND PROCEDURES
3
1
3
Table 3-4. Cab Controls and Indicators
Item Name Description
1 Louvers Vents to circulate air in the operator’s cab.
2 Travel Foot Pedals See page 3-28
for more information.
3 Not Used
4 Front Windshield Wiper See page 3-23
for more information.
5 Windshield Washer Fluid Reservoir Container for washer fluid.
6 Camera Monitors
The camera screen displays camera options and items for selecting
and operating. Camera options include up to eight different cameras to
monitor drum spooling and area behind the crane.
See page 3-35
for more information.
7 Right Console See page 3-18
for more information.
8 Right Window Latch
Right window latch is used to open the window for ventilation and as an
emergency exit. See page 3-58
for more information.
9 Sun Visor
A visor is provided for the front window. Position the visor as desired to
shade the sunlight.
10 Sun Shade
Shades are provided for the roof and side windows. Position the
shades as desired to shade the sunlight.
11 Upperworks Level See page 3-31
for more information.
12 Radio Antenna See page 3-18
for radio information.
13 Rated Capacity Limiter (RCL) Light
The beacon rotates and the alarm sounds whenever the crane’s
capacity is near an overload condition (when RCL system is ON). See
page 3-31
.
14 Fire Extinguisher
Used to extinguish class A, B, and C fires. Standard extinguisher is in
the cab. An optional extinguisher is mounted on the left side of the
rotating bed to the rear of the cab.
15 Upper Windshield Wiper See page 3-23
for more information.
16 Cup Holder Provided for operator convenience.
17 Cargo Net Provided for storage.
18 HVAC Outdoor Air Ventilation Air terminal supplies outdoor air.
19 RCL Override Assembly Switch
On cranes meeting CE requirements, an RCL/RCI override switch is
provided outside the cab in a lockable box.
The override switch allows emergency operation of the crane functions
in case of RCL/RCI component failures: boom angle sensor, luffing jib
angle sensor, and load sensing sheaves (load pins).
• When the external override is on, the speed of the crane functions is
limited to 15% of their maximum speed for load increasing actions.
• Actuation of the external override and all relevant data is recorded in
a data recorder.
20 Rear View Mirror
Adjustable rear-view mirror. Standard mirror is mounted on the cab. An
optional mirror is mounted on the right-front side of rotating bed.
21 Storage Compartment
Store the setup remote control and the portable crane service lights in
this compartment. The door latch can be locked with the provided key.
22 Decal - Outside Air Ventilation Displays the positions of the air control handle.
