7 Additional settings
7.14 DC supply
Risk of irreparable damage when using a DC supply
Servo drives of the BL 4000-C series must not be supplied with DC voltage via the DC
bus terminals (DC supply).
7.15 Control circuit cycle times
Risk of irreparable damage due to incorrect settings
Only experienced users should change the configuration.
Incorrect settings can cause the drive to oscillate, thereby destroying the motor.
Use the menu Parameters/Controller parameters/Cycle times to change the cycle times
of the internal control circuits, e.g. of the current control circuit. The following window will
be displayed:
Figure 113: "Cycle times" window - "Setpoints" tab
To open the Setpoints tab, click the Settings button.
Product manual BL 4000-C Page 187 of 298
