13 Electrical installation
13.8 Connector: standard Ethernet [X18]
The BL4100-C servo drive has a network connector of the RJ45 type.
Configuration on the device [X18]
Female RJ45 connector, cat. 6
Mating connector [X18]
Male RJ45 connector
Pin assignment of the network connector [X18]
Cat.6 patch cable RJ45 LAN cable S-FTP/PIMF.
Figure 142: Pin assignment of the network connector
Pin Name Description Colour
1 TX+ Transmission signal + Yellow
2 TX- Transmission signal - Orange
3 RX+ Reception signal + White
4 - -
5 - -
6 RX- Reception signal - Blue
7 - -
8 - -
Product manual BL 4000-C Page 251 of 298
