This chapter provides all of the relevant technical data of the
BL4100-C servo drive with an integrated "Safe Torque Off (STO)" safety function.
12.1 General technical data
Ambient conditions and qualification
Characteristic Value
Storage temperature -25°C to +70°C
Ambient temperature 0°C to +40°C
+40°C to +50°C with a power reduction of 2.5%/K
Permissible installation altitude Max. installation altitude 2,000 m above MSL;
with a power reduction of 1% per 100 m as of 1,000 m
above MSL
Atmospheric humidity Relative humidity up to 90%, non-condensing
Type of enclosure IP20
Protection class I
Pollution degree rating 2
Compliance with the pollution degree rating
The integrated safety technology requires compliance with pollution degree rating 2 and
thus a protected enclosure (IP54). This must always be ensured through appropriate
measures, e.g. through installation in a control cabinet.
Dimensions and weight
*)
Characteristic Value
Dimensions including the mounting plate
(H * W * D)
245 mm * 50 mm * 163 mm
Housing dimensions (H * W * D) 200 mm * 50 mm * 163 mm
Weight approx. 1.5 kg
*) Device dimensions without the mating connector.
Product manual BL 4000-C Page 215 of 298
