11 Installation
The following requirements must be fulfilled for the installation of the servo drive:
l Follow the general set-up and safety rules and regulations concerning the
installation.
l Follow the safety instructions in section 2.6 Safety notes for installation and
maintenance on page 19.
l Use only suitable tools. If specified, use special tools.
l Always use suitable personal protective equipment, see section 2.5 Personal
protective equipment on page 19.
l Servo drives of the BL 4100-C series are intended for use as devices installed in
control cabinets.
l Installation position: Vertical with supply lines [X9] on top.
l The BL 4100-C servo drives have fastening tabs at the top and bottom. These tabs
are used to mount the servo drive vertically to a control cabinet plate.
l Recommended tightening torque for an M5 screw of property class 5.6: 2.8 Nm.
l Keep a minimum distance of 100 mm above and under the device with regard to
other components in order to ensure sufficient ventilation. For optimal wiring of the
motor cable and angle encoder cable under the device, an installation clearance of
150 mm is recommended.
l The BL 4100-C servo drives may be installed directly next to one another on a heat-
dissipating back plate, provided that they are installed properly and used as
intended. Excessive heating may cause premature ageing and/or damage.
Product manual BL 4000-C Page 214 of 298
