3 Product description
Top view / bottom view
Figure 3: Top view / Bottom view
14 [X9] Power supply 17 [X2A] Resolver/ analogue Hall sensors
15 [X6] Motor connection 18 Slot for microSD cards
16 [X2B] Multi-encoder 19 [X1] I/O communication
