8 Settings Related to Output Control
108
1. Press once to display .
2. Press .
Function mode is activated, and the display changes to a two-digit numerical value prefixed by
[F-].
3. Using and , change the numerical value to any of , ,
, , , and , then press .
A two-digit number showing the currently set external control output function appears.
Number Function
00
Does not use the external control output function.
01
Show that the hold mode is active.
02
Show that the [PEAK] LED is turned on.
03
Show that the [MEAS.] LED is turned on.
04
Show that the [END] LED is turned on.
05
Show that multimode is active.
06
Show that measurement is underway in multimode.
07
Show that the results of waveform comparison and detection result judgment are
acceptable.
08
Show that the results of waveform comparison and detection result judgment are
unacceptable.
09
Show that the result of the detection result judgment exceeds the upper limit.
10
Show that the open collector of S0 is turned on in the comparator.
11
Show that the open collector of S1 is turned on in the comparator.
12
Show that the open collector of S2 is turned on in the comparator.
13
Show that an error occurred.
14
Show that an overload occurred.
15
Show that the zero set was executed.
16
Use the level output to show that measurement is underway.
17
U
se the toggle output having a period of 500 ms to show that measurement is underway.
00
For setting procedures with and , see Section 1.6, "Basic key operation".
4. Using and , set the external control output function, then press .
5. To set the external control output function to other functions, repeat Steps 3 and 4.
Default
