10 Communications via USB
117
The contents relative to the USB interface should be set to the following functions, respectively.
Function Setting details
F-40
Operating modes
F-41
Output target in the Stream mode or Print command synchronization mode
F-42
Communication method based on the USB interface
F-43
Addition/Removal of decimal point to/from output data
F-44
Number of digits of the unit to be output under combination of load display and status
CF-05
Unit character to be output
Described below are the procedures for setting the contents related to the USB interface.
1. Press once to display .
2. Press .
Function mode is activated, and the display changes to a two-digit numerical value prefixed by
[F-].
3. Using and , change the numerical value to , then press .
The number showing the current operating mode appears.
Number Operating modes
0
Command mode
1
Stream mode
2
Print command synchronization mode
0 (Command mode)
For setting procedures with and , see Section 1.6, "Basic key operation".
4. Using , set the operating mode, then press .
Whenever is pressed, the number times through the values from 0 to 2 in ascending order.
5. After confirming is displayed, press .
The number showing the currently set output target appears.
Number Output target
0 Interlock with display in the load window
1 Track
2 Peak
3 Combination of load display and status
0 (Interlock with display in the load window)
6. Using , set the output target, then press .
Whenever is pressed, the number times through the values from 0 to 3 in ascending order.
The output target will be enabled after Stream mode or Print command synchronization mode is set
as the operating mode.
Default
Default
