A Specifications of CSD-709
139
A.11 Option
A.11.1 Current output
Model CSD-709-07
Specifications
Output
DC4 mA ~ 20 mA
Load resistance
510 , max
Resolution 1/12 000, min
Non-linearity 0.025 %F.S.
Over-range
Approx. DC 2.4 mA under display of [-OL],
Approx. DC 21.6 mA under display of [OL].
Output times Synchronized with AD sampling
Influence of
temperature
Zero point: 0.5 A/°C
Sensitivity: 0.005 %F.S./°C
A.11.2 Voltage output
Model CSD-709-29
Specifications
Output DC ± 10 V
Load resistance
2 k, min
Resolution 1/12 000, min
Non-linearity 0.025 %F.S.
Over-range
Approx. -11 V under display of [-OL],
Approx. 11 V under display of [OL].
Output times Synchronized with AD sampling
Influence of
temperature
Zero point: 0.6 mV/°C
Sensitivity: 0.005 %F.S./°C
A.11.3 BCD output (sink type)
Model CSD-709-15
Specifications Output BCD five-digit parallel output
Accompanied by polarity (POL.) (Output is turned on at negative
polarity and turned off at positive polarity.)
P.C. (print command): Turned on for a given period after
completion of BCD output conversion
ERROR: Turned on whenever any error occurs.
OVER
Output
times
Can be changed to 4, 20, 50, 100, 400, 1 000, 2 000, or 4 000
times/s
Input SEL.1, SEL2: You can select the desired brand code.
HOLD: Display or BCD output is held.
BCD-ENABLE: BCD-related outputs are forcibly turned off (high
impedance).
