A Specifications of CSD-709
140
A.11.4 BCD output (source type)
Model CSD-709-16
Specifications Output BCD five-digit parallel output
Accompanied by polarity (POL.) (Output is turned on at negative
polarity and turned off at positive polarity.)
P.C. (print command): Turned on for a given period after
completion of BCD output conversion
ERROR: Turned on whenever any error occurs.
OVER
Output
times
Can be changed to 4, 20, 50, 100, 400, 1 000, 2 000, or 4 000
times/s
Input SEL.1, SEL2: You can select the desired brand code.
HOLD: Display or BCD output is held.
BCD-ENABLE: BCD-related outputs are forcibly turned off (high
impedance).
A.11.5 External control voltage input type circuit
Model CSD-709-44
Specifications Signal is output by applying a voltage between input and COM1 terminals.
A.11.6 RS-232C interface
Model CSD-709-74
Specifications Baud rate Select 1 200 bps, 2 400 bps, 4 800 bps, 9 600 bps,
19 200 bps, 38 400 bps, 76 800 bps, or 115 200 bps.
Data bit length Select [7 bit] or [8 bit].
Parity bit Select [No parity], [Even parity], or [Odd parity].
Stop bit Select [1 bit] or [2 bit].
Terminator Select [CR] or [CR+LF].
Transmission mode Half-duplex
Sync mode Asynchronous
Transmission data ASCII code
Cable length 15 m, max; equipped with input/output monitor LED
