A Specifications of CSD-709
141
A.11.7 RS-422/RS-485 interface
Model CSD-709-76
Specifications Baud rate Select 1 200 bps, 2 400 bps, 4 800 bps, 9 600 bps,
19 200 bps, 38 400 bps, 76 800 bps, or 115 200 bps.
Data bit length Select [7 bit] or [8 bit].
Parity bit Select [No parity], [Even parity], or [Odd parity].
Stop bit Select [1 bit] or [2 bit].
Terminator Select [CR] or [CR+LF].
Transmission mode Half-duplex
Sync mode Asynchronous
Address Select one address within the range from 0 to 31.
Transmission data ASCII code
Cable length Approx. 1 km
No. of connections 32 units, max (RS-422: 10 units)
Termination Built in (Existence or nonexistence is selected by
plugging in the connector board); equipped with
input/output monitor LED
Change between
RS-422 and RS-485
Function is used.
A.11.8 Serial interface (SI/F)
Model CSD-709-77
Specifications Baud rate
600 bps
Data bit length
8 bit
Parity bit
Odd
Stop bit
1 bit
Start bit 1 bit
Transmission mode Binary code or BCD
A.11.9 Power supply voltage
Model CSD-709-67
Specifications
Power supply 12 VDC ~ 24 VDC (10.6 VDC ~ 27.6 VDC)
Power
consumption
Approx. 3.6 W (@ 24 VDC; no option)
Approx. 4.9 W, max (@ 24 VDC; equipped with optional
CC-Link)
Inrush current 600 mA (20 ms) in 12 VDC average load condition (ordinary
temperature and cold start)
250 mA (50 ms) in 24 VDC average load condition (ordinary
temperature and cold start)
