A.11.10 CC-Link interface
Model CSD-709-73
Specifications CC-Link version Ver.1.10
Number of shared
stations
Select 1, 2, or 4.
Baud rate Select 156 kbps, 625 kbps, 2.5 Mbps, 5 Mbps,
or 10 Mbps.
Communication
system
Polling
Sync mode Bit synchronous
Transmission path RS-485 bus
Transmission format Conforming to HDLC
Remote station
number
01 ~ 64 (one station is shared), 01 ～ 63 (two stations
are shared), or 01 ~ 61 (four stations are shared)
No. of connections Up to 64 (one station is shared), up to 32 (two stations are
shared), or up to 16 (four stations are shared)
Connecting cable Shielded twisted-pair cable. The cable used shall be
specialized for the CC-Link.
Termination External resistor
Status LEDs Communication status is indicated with the associated
LED (RUN, ERR, SD, or RD).
A.11.11 Additional memory
Model CSD-709-91
Specifications Calendar function is available. Comparator judgment result, peak, and error log
can be stored. The stored data can be read using the specialized software.
