D Detection Operation and Section
149
D.1.4 Peak-to-peak hold
In the peak-to-peak hold mode, the difference between the peak and bottom is held.
D.1.5 Maximum, minimum, and maximum-minimum difference
When the peak-to-peak value deviates from the detection data width set to P function PF-11, the
current peak is held as a maximum.
A (Maximum)
B
Peak-to-peak value
Detection data width
A (Bottom)
B (Peak)
X (Peak-to-peak value)
