D Detection Operation and Section
150
In actual measurements, the maximum is held as shown below.
When the peak-to-peak value deviates from the detection data width and then the difference
between the bottom and the track exceeds the detection magnification set to P function PF-12, the
bottom is held as a minimum.
Detection data width
B (Minimum)
X
Detection
magnification
Y
C
A
