J Communications Based on Modbus Protocol
188
J.3.2 Input status
The input status offers reference functions using a binary-coded bit. Shown below is the data that
can be referenced by the input status.
Data Address
SEL1 17
SEL2 18
CHECK 19
HOLD 20
PEAK 21
MEAS. 22
END 23
LOCK 24
OUTPUT1 25
OUTPUT2 26
OUTPUT3 27
OUTPUT4 28
OUTPUT5 29
OUTPUT6 30
MULTI (multimode is used) 33
EXCUTE (measurement in the multimode) 34
OK 35
NG 36
Upper limit / lower limit 37
S0 38
S1 39
S2 40
Error 41
Faulty weight 42
