J Communications Based on Modbus Protocol
189
J.3.3 Input register
The input register offers reference functions using a 16-bit length word. Shown below is the data that
can be referenced by the input register.
Data Address
Decimal place 1
Unit 2
Track 5
Peak 7
Faulty weight 13
Error 15
Status 1 51
Status 2 52
Status error code 53
Track 54 ~ 55
Status 1 56
Status 2 57
Status error code 58
Peak 59 ~ 60
Status 1 61
Status 2 62
Status error code 63
Software version 99
In Status 1, the following statuses are represented by bits.
Bit position Details
15 SEL1
14 SEL2
13 CHECK
12 HOLD
11 PEAK
10 MEAS.
9 END
8 LOCK
7 OUTPUT1
6 OUTPUT2
5 OUTPUT3
4 OUTPUT4
3 OUTPUT5
2 OUTPUT6
1
0
