J Communications Based on Modbus Protocol
190
In Status 2, the following statuses are represented by bits.
Bit position Details
15 MULTI (multimode is used)
14 EXCUTE (measurement in the multimode)
13 OK
12 NG
11 Upper limit / lower limit
10 S0
9 S1
8 S2
7 Error
6 Faulty weight
5
4
3
2
1
0
When errors occur, error codes are represented by the status error codes shown below.
Error code Cause
1 Zero set is executed outside the effective zero set range.
2 Invalid function is specified.
10 Load exceeds the display range.
11 Load falls below the display range.
12 Result of AD conversion is overflown.
13 Result of AD conversion is overflown.
20 Zero point in the calibration is below the specified value.
21 Zero point in the calibration is higher than the specified value.
22 Actual load in the calibration is lower than the specified value.
23 Actual load in the calibration is higher than the specified value.
