Minebea CSD-709 User Manual

Function Setting Table
202
Function Setting details Setting Default Referent
F−18 Hold target 0 (Off), 1 (On).
First digit: Display in the
load window,
Second digit: Result of
comparison with
the comparator,
Third digit: Output of load by
means of option
001
(Display only)
7.9 Setting hold targets
F−21 Comparator
operation target
0 (Track),
1 (Peak).
First digit: S0, Second digit: S1,
Third digit: S3
000 6.3 Setting the
comparator operating
condition
F−22 Comparator
operating
conditions
0 (Always turned off),
1 (Turned on at or above the
comparison value),
2 (Turned on at or below the
comparison value).
First digit: S0, Second digit: S1,
Third digit: S2
000 6.3 Setting the
comparator operating
condition
F−24 Comparator
hysteresis
operating
conditions
0 (ON delay),
1 (OFF delay)
0 (ON delay) 6.4 Setting the
comparator hysteresis
F−25 Comparator
hysteresis data
width
00 ~ 99
00 6.4 Setting the
comparator hysteresis
F−26 Comparator
hysteresis duration
00 ~ 99
(Time width = Setting × 0.1 s)
00 6.4 Setting the
comparator hysteresis
F−30 BCD output
operation
0 (Stream mode),
1 (Print command
synchronization)
0 (Stream
mode)
G.3 Setting
F−31 Setting of BCD
output target
0 (Display interlock),
1 (Track),
2 (Peak)
0 (Display
interlock)
G.3 Setting
F−32 Setting of BCD
output logic
0 (Negative logic),
1 (Positive logic).
First digit: Data output logic,
Second digit: Polarity output
logic,
Third digit: Plug output logic,
Fourth digit: P.C. output logic
0000 G.3 Setting
F−33 BCD PC width 0 (125 ms), 1 (25 ms),
2 (10 ms), 3 (5 ms),
4 (1.25 ms), 5 (0.5 ms),
6 (0.25 ms) , 7 (0.125 ms)
1 (25 ms) G.3 Setting
F−34 BCD output
frequency
0 (4 times/s), 1 (20 times/s),
2 (50 times/s), 3 (100 times
/
s),
4 (400 times/s),
5 (1 000 times/s),
6 (2 000 times/s) ,
7 (4 000 times/s)
0 (4 times/s) G.3 Setting
