Function Setting Table
208
C function
Setting details Setting Default Referent
CF−33 Voltage output 1 -
output target
0 (Display interlock),
1 (Track),
2 (Peak)
0 (Display
interlock)
E.2 Setting, F.2 Setting
CF−34 Voltage output 1 -
Setting of zero
output
-99 999 ~ 99 999
0 E.2 Setting, F.2 Setting
CF−35 Voltage output 1 -
Setting of span
output
-99 999 ~ 99 999
10 000 E.2 Setting, F.2 Setting
CF−36 Voltage output 2 -
output target
0 (Display interlock),
1 (Track),
2 (Peak)
0 (Display
interlock)
E.2 Setting, F.2 Setting
CF−37 Voltage output 2 -
Setting of zero
output
-99 999 ~ 99 999
0 E.2 Setting, F.2 Setting
CF−38 Voltage output 2 -
Setting of span
output
-99 999 ~ 99 999
10 000 E.2 Setting, F.2 Setting
CF−39 Voltage output 3 -
output target
0 (Display interlock),
1 (Track),
2 (Peak)
0 (Display
interlock)
E.2 Setting, F.2 Setting
CF−40 Voltage output 3 -
Setting of zero
output
-99 999 ~ 99 999
0 E.2 Setting, F.2 Setting
CF−41 Voltage output 3 -
Setting of span
output
-99 999 ~ 99 999
10 000 E.2 Setting, F.2 Setting
CF−42 Selection of
number of digits in
decimal place
(calibration data 1)
0 (No display),
1 (Up to first decimal place),
2 (Up to second decimal
place),
3 (Up to third decimal place),
4 (Up to fourth decimal place)
0 (No display) 3.3 Setting the decimal
point display position
CF−43 Selection of
number of digits in
decimal place
(calibration data 2)
Ditto 0 (No display) 3.3 Setting the decimal
point display position
CF−44 Selection of
number of digits in
decimal place
(calibration data 3)
Ditto 0 (No display) 3.3 Setting the decimal
point display position
CF−50 Calibration data 0 -
Unit weight
0 3.8
Verifying the
registered calibration data
CF−51 Calibration data 0 -
Measuring weight
0 3.8
Verifying the
registered calibration data
CF−52 Calibration data 0 -
Weight mass
0 3.8
Verifying the
registered calibration data
CF−53 Calibration data 0 -
mV/V value of zero
point
0 3.8
Verifying the
registered calibration data
To Next Page
