Minebea CSD-709 User Manual

Function Setting Table
210
▼ P function
P function Setting details Setting Default Referent
PF−01 Detection
operation
00 (Peak), 01 (Bottom),
02 (Peak-bottom),
03 (Peak-to-peak),
04 (Maximum), 05 (Minimum),
06 (Maximum-minimum
difference),
07 (Inflection point A),
08 (Inflection point B),
09 (Inflection point C),
10 (Inflection point D),
11 (Average)
00 (Peak) 5.1.3 Setting the
detection operation
PF−02 Designation of
section
0 (Entire section),
1 (Specified section),
2 (Time-specified section),
3 (Automatic start
time-specified section)
0 (Entire
section)
5.1.2 Setting the
detecting section
PF−03 Change between
single mode and
multimode
0 (Single mode),
1 (Multimode)
0 (Single
mode)
5.2.1 Entering into the
multimode
PF−09 Selection of detecting
condition number
0 ~ 7
0 5.1.1 Detection
condition number
PF−10 Setting of
reference point
(peak and bottom)
-99 999 ~ 99 999
0 5.1.3 Setting the
detection operation
PF−11 Detection data
width (maximum
and minimum)
0 ~ 99 999
200 5.1.3 Setting the
detection operation
PF−12 Detection
magnification
(maximum and
minimum)
0 ~ 49
(Detection magnification =
Setting × 0.1)
15 (× 1.5) 5.1.3 Setting the
detection operation
PF−20 Inflection point A -
Detection data width
-99 999 ~ 99 999
100 5.1.3 Setting the
detection operation
PF−21 Inflection point A -
Detection time A
0 ~ 450
100 ms 5.1.3 Setting the
detection operation
PF−22 Inflection point A -
Detection time B
0 ~ 450
100 ms 5.1.3 Setting the
detection operation
PF−23 Inflection point A -
Detection fine
adjustment
0 ~ 10
0 5.1.3 Setting the
detection operation
PF−24 Inflection point B -
Detection data width
-99 999 ~ 99 999
100 5.1.3 Setting the
detection operation
PF−25 Inflection point B -
Detection time A
0 ~ 450
100 ms 5.1.3 Setting the
detection operation
PF−26 Inflection point B -
Detection time B
0 ~ 450
100 ms 5.1.3 Setting the
detection operation
PF−27 Inflection point B -
Detection fine
adjustment
0 ~ 10
0 5.1.3 Setting the
detection operation
PF−28 Inflection point C -
Detection data width
-99 999 ~ 99 999
100 5.1.3 Setting the
detection operation
