Minebea CSD-709 User Manual

Function Setting Table
211
P function Setting details Setting Default Referent
PF−29 Inflection point C -
Detection time A
0 ~ 450
100 ms 5.1.3 Setting the
detection operation
PF−30 Inflection point C -
Detection time B
0 ~ 450
100 ms 5.1.3 Setting the
detection operation
PF−31 Inflection point C -
Detection fine
adjustment
0 ~ 10
0 5.1.3 Setting the
detection operation
PF−32 Inflection point D -
Detection data
width
-99 999 ~ 99 999
100 5.1.3 Setting the
detection operation
PF−33 Inflection point D -
Detection time A
0 ~ 450
100 ms 5.1.3 Setting the
detection operation
PF−34 Inflection point D -
Detection time B
0 ~ 450
100 ms 5.1.3 Setting the
detection operation
PF−35 Inflection point D -
Detection fine
adjustment
0 ~ 10
0 5.1.3 Setting the
detection operation
PF−40 Hold detection
time
0 ~ 10 000
1 000 ms 5.1.3 Setting the
detection operation
PF−41 Automatic start
level
-99 999 ~ 99 999
1 000 5.1.2 Setting the
detecting section
PF−42 Average update
time
50 ~ 1 000
50 ms 5.1.3 Setting the
detection operation
PF−43 Detection prohibit
time
00 ~ 10 (Detection time =
Setting × 0.1)
0 s 5.1.5 Setting the
detection prohibit time
PF−50 Waveform
comparison and
detection result
judgment
0 (Disable),
1 (Detection result judgment),
2 (Waveform comparison)
0 (Disable) 5.3 Detection result
judgment and waveform
comparison
PF−51 Upper limit -99 999 ~ 99 999 99 999 5.3 Detection result
judgment and waveform
comparison
PF−52 Lower limit -99 999 ~ 99 999 −99 999 5.3 Detection result
judgment and waveform
comparison
PF−90 Detection condition
number for Area 1
0 ~ 7, -1 (Not used)
0 5.2.2 Assigning the
execution order
PF−91 Detection condition
number for Area 2
0 ~ 7, -1 (Not used)
-1
(Not used)
5.2.2 Assigning the
execution order
PF−92 Detection condition
number for Area 3
0 ~ 7, -1 (Not used)
-1
(Not used)
5.2.2 Assigning the
execution order
PF−93 Detection condition
number for Area 4
0 ~ 7, -1 (Not used)
-1
(Not used)
5.2.2 Assigning the
execution order
PF−99 Memory clear − − 7.10 Initialization of
setting
