5 Settings Related to Detection
66
11. After confirming is displayed, press .
The currently set fine adjustment in detection appears.
0
12. Using and , set the fine adjustment in detection.
You can set any value between 0 and 10, which will be displayed in the load window.
13. Press .
14. Press twice to return to Measurement mode.
▼ Setting the average update time [PF-42]
When you have selected [11] (Average) as the desired detection operation, you should set the
average update time to P function PF-42. Described below are the average update time setting
procedures.
1. Press once to display .
2. Press twice to change the display to .
3. Press .
The P function mode is activated, and the display changes to a two-digit numerical value
prefixed with [PF-].
4. Using and , change the numerical value to and press .
The currently set average update time appears in [ms].
50 ms
For setting procedures with and , see Section 1.6, "Basic key operation".
5. Using and , set the average update time.
You can set any value between 50 ms and 1 000 ms.
6. Press .
7. Press twice to return to Measurement mode.
5.1.4 Setting example of detecting condition
This section gives examples of setting four detecting conditions below.
Detection of a peak in the entire section
Detection of a bottom in the specified section
Detection of a maximum in the time-specified section
Detection of an inflection point in the automatic start time-specified section
Default
Default
