3 - 12
DIAGRAMS
Jam
code
Method of clearing jam
If a copy is being
made when a jam
occurs, copy operation
is stopped after
completion of exit of
the copy.
The main body is
stopped immediately.
If a copy is being
made when a jam
occurs, copy operation
is stopped after
completion of exit of
the copy.
Open the LCT upper
cover and remove the
jammed paper and close
it.
Open the front door and
remove the jammed
paper and close it.
Open the conveyance
door and remove the
jammed paper and close
it.
J15-1
J15-2
J15-3
J16
J17-1
J17-2
J17-3
J17-4
J17-5
J17-6
J19
Classifica-
tion
Causes
Operation when jam
occurs
Large
capacity tray
paper feed
jam
Conveyance
jam
When
stationary
When
operating
When
stationary
When
operating
When
stationary
When
operating
When
stationary
When
operating
Main body and LCT Large capacity tray
PS802 (pre try) is ON during idling.
PS802 (pre try) is not turned ON
within 400 msec from ON of MC800
(paper feed).
PS804 (no feed) is not turned ON
within 800 msec from ON of PS802
(pre tray).
PS14 (register) is ON during idling.
An original jammed in the ADF during
a copy operation.
PS18 (no feed) or PS19 (optics sync)
is ON during idling.
PS157 (ADU gate) is turned ON
within 280 msec from start of copy-
ing.
PS19 (optics sync) is not turned ON
within 560 msec from ON of PS157
(ADU gate).
PS19 (optics sync) is not turned ON
within 430 msec from the start of
reconveyance in right lengthwise
transport in LCT paper feed.
PS18 (no feed) is not turned ON
within 560 msec from the start of
reconveyance in right lengthwise
transport in LCT/ADU reverse side.
A loop is not completed within 400
msec from ON of a PS18 (no feed).
PS146 (LCT conveyance (1500)) is
ON when the machine is idling.
PS146 (LCT conveyance (1500))
does not go ON within 300 ms after
SD141 (LCT paper feed (1000)) go
ON, or within 440 ms after SD140
(LCD paper feed (1500)) go ON.
To Next Page
