3 - 13
DIAGRAMS
Jam
code
Method of clearing jam
The main body is
stopped immediately.
Open the front door and
remove the jammed
paper and close it.
Open the paper exit and
the front door and
remove the jammed
paper and close them.
J21
J30
J31
J32
Classifica-
tion
Main body and LCT
Causes
Operation when jam
occurs
Conveyance
jam
Paper wrapping is detected by
TCSB
.
PS14 (regist) is not turned OFF within
paper size length + 40 mm from ON
of MC3 (2nd paper feed).
PS25 (paper exit) is not turned ON
within 2000 msec from ON of MC3
(2nd paper feed).
PS25 (paper exit) was turned ON
within 280 msec from copy start.
PS25 (paper exit) is ON during idling.
PS25 (paper exit) does not go OFF
within 2000 msec after PS25 goes
ON.
When
stationary
When
operating
