3 - 14
DIAGRAMS
Jam
code
Method of clearing jam
ADF is stopped
immediately.
When there is paper in
or after transfer, the
main body is stopped
after exit of the paper.
Open ADF and remove
the jammed paper and
close it.
If there is a jammed
paper on a conveyance
unit in the main body,
remove it.
J61
J62
J63
Classifica-
tion
Causes
Operation when jam
occurs
ADF
paper feed
jam
ADF
paper exit
jam
When
operating
When
stationary
When
operating
When
stationary
When
operating
ADF
ADF was opened during ADF
operation.
PS302 (original passing) is ON dur-
ing idling in ADF mode.
PS302 (original passing) is not
turned ON within a certain period
from the start of ADF original.
PS302 (original passing) is not
turned OFF within a certain period
from its ON.
PS302 (original passing) ON when
original setting is completed.
PS306 (original exit) is ON during
idling in ADF mode.
PS306 (original exit) is not turned
ON within a certain period from the
start of ADF original exit.
PS306 (original exit) is not turned
OFF within a certain period from its
ON.
PS306 (original exit) is not turned
ON within a certain period from the
start of RADF original reversing.
To Next Page
