3 - 15
DIAGRAMS
Jam
code
Method of clearing jam
Finisher/main body is
stopped immediately.
Remove the jammed
paper off the finisher/
main body.
Classifica-
tion
Causes
Operation when jam
occurs
When
stationary
Finisher
PS4 (FIN entrance passing)
detected paper.
PS5(stacker conveyance passing)
detected paper.
PS4(FIN entrance passing)and
PS5(stacker conveyance passing)
detected paper.
PS6(paper exit 1)detected paper.
PS4(FIN entrance passing) and
PS6(paper exit 1) detected paper.
PS5(stacker conveyance passing)
and PS6(paper exit 1)detected pa-
per.
PS4(FIN entrance passing), PS5
(stacker conveyance passing) and
PS6(paper exit 1)detected paper.
PS1(printer paper exit)is ON.
PS1(Printer paper exit) and PS4
(stacker conveyance passing) are
ON.
PS1(Printer paper exit) and
PS5(stacker conveyance passing)
are ON.
PS1(Printer paper exit), PS5(stacker
conveyance passing)and PS4(FIN
entrance passing)are ON.
PS1(Printer paper exit) and PS6
(Paper exit 1) are ON.
PS1(Printer paper exit), PS4 (FIN
entrance passing) and PS6 (Paper
exit 1) are ON.
PS1(Printer paper exit), PS5
(Stacker conveyance passing) and
PS6 (Paper exit 1) are ON.
PS1(Printer paper exit), PS6(paper
exit 1), PS5 (stacker conveyance
passing) and PS4(FIN entrance
passing) are ON.
PS20(stacker paper 0) is ON.
PS20(stacker paper 0) and PS4 (FIN
entrance passing) are ON.
PS20 (stacker paper 0) and PS5
(Stacker conveyance passing) are
ON.
PS20(stacker paper 0), PS5 (stac-
ker conveyance passing), and
PS4(FIN entrance passing ) are ON.
PS20(Stacker paper 0) and PS6
(paper exit 1) are ON.
PS20(stacker paper 0), PS4 (FIN
entrance passing) and PS6 (Paper
exit 1) are ON.
J72-01
J72-02
J72-03
J72-04
J72-05
J72-06
J72-07
J72-08
J72-09
J72-10
J72-11
J72-12
J72-13
J72-14
J72-15
J72-16
J72-17
J72-18
J72-19
J72-20
J72-21
Finisher
